1.8° 28mm Hybrid Stepper Motor-NEMA11

    Buy cheap 1.8° 28mm Hybrid Stepper Motor-NEMA11 from wholesalers

    Buy cheap 1.8° 28mm Hybrid Stepper Motor-NEMA11 from wholesalers
    • Buy cheap 1.8° 28mm Hybrid Stepper Motor-NEMA11 from wholesalers

    1.8° 28mm Hybrid Stepper Motor-NEMA11

    Ask Lasest Price
    Brand Name : DAITTO
    Certification : ISO,CE
    Model Number : DA28HS32-0674
    • Product Details
    • Company Profile

    1.8° 28mm Hybrid Stepper Motor-NEMA11


    Genaral Specification:

    Item
    Specifications
    Step Angle
    1.8°
    Temperature Rise
    80℃max
    Ambient Temperature
    -20℃~+50℃
    Insulation Resistance
    100 MΩ Min. ,500VDC
    Dielectric Strength)
    500VAC for 1minute
    Shaft Radial Play
    0.02Max. (450g-load)
    Shaft Axial Play
    0.08Max. (450g-load)
    Max. radial force
    28N (20mm from the flange)
    Max. axial force
    10N

    Electrical Specification:
    Model No.
    Step Angle
    Motor Length
    Current
    /Phase
    Resistance
    /Phase
    Inductance
    /Phase
    Holding Torque
    # of Leads
    Rotor Inertia
    Motor
    Weight
    ( °)
    (L)mm
    A
    Ω
    mH
    g.cm
    No.
    g.cm
    Kg
    DA28HS32-0956
    1.8
    32
    0.95
    2.8
    0.8
    430
    6
    9
    0.11
    DA28HS32-0674
    1.8
    32
    0.67
    5.6
    3.4
    600
    4
    9
    0.11
    DA28HS45-0956
    1.8
    45
    0.95
    3.4
    1.2
    750
    6
    12
    0.14
    DA28HS45-0674
    1.8
    45
    0.67
    6.8
    4.9
    950
    4
    12
    0.14
    DA28HS51-0956
    1.8
    51
    0.95
    4.6
    1.8
    900
    6
    18
    0.2
    DA28HS51-0674
    1.8
    51
    0.67
    9.2
    7.2
    1200
    4
    18
    0.2
    1.8° 28mm Hybrid Stepper Motor-NEMA11
    1.8° 28mm Hybrid Stepper Motor-NEMA11
    Quality 1.8° 28mm Hybrid Stepper Motor-NEMA11 for sale
