1.8° 35mm Hybrid Stepper Motor-NEMA14

    Buy cheap 1.8° 35mm Hybrid Stepper Motor-NEMA14 from wholesalers

    Buy cheap 1.8° 35mm Hybrid Stepper Motor-NEMA14 from wholesalers
    • Buy cheap 1.8° 35mm Hybrid Stepper Motor-NEMA14 from wholesalers
    • Buy cheap 1.8° 35mm Hybrid Stepper Motor-NEMA14 from wholesalers

    1.8° 35mm Hybrid Stepper Motor-NEMA14

    Ask Lasest Price
    Brand Name : DAITTO
    Certification : ISO,CE
    Model Number : DA35HY34-1004
    • Product Details
    • Company Profile

    1.8° 35mm Hybrid Stepper Motor-NEMA14

    1.8° 35mm Hybrid Stepper Motor-NEMA14

    Genaral Specification:

    Item
    Specifications
    Step Angle
    1.8°
    Temperature Rise
    80℃max
    Ambient Temperature
    -20℃~+50℃
    Insulation Resistance
    100 MΩ Min. ,500VDC
    Dielectric Strength
    500VAC for 1minute
    Shaft Radial Play
    0.02Max. (450g-load)
    Shaft Axial Play
    0.08Max. (450g-load)
    Max. radial force
    28N (20mm from the flange)
    Max. axial force
    10N

    Electrical Specifications:

    Model No.
    Step Angle
    Motor Length
    Current
    /Phase
    Resistance
    /Phase
    Inductance
    /Phase
    Holding Torque
    # of Leads
    Detent Torque
    Rotor Inertia
    Motor
    Weight
    ( °)
    (L)mm
    A
    Ω
    mH
    g.cm
    No.
    g.cm
    g.cm
    Kg
    DA35HY26-0284
    1.8
    26
    0.28
    26
    27
    700
    4
    60
    10
    0.13
    DA35HY28-0504
    1.8
    28
    0.5
    20
    18
    1000
    4
    80
    11
    0.14
    DA35HY34-1004
    1.8
    34
    1.0
    2.7
    4.3
    1400
    4
    100
    14
    0.18
    DA35HY36-1004
    1.8
    34
    1.0
    2.7
    4.3
    1400
    4
    110
    15
    0.19
