1.2°3phase Hybrid Stepper Motor-NEMA42

    Buy cheap 1.2°3phase Hybrid Stepper Motor-NEMA42 from wholesalers

    Buy cheap 1.2°3phase Hybrid Stepper Motor-NEMA42 from wholesalers
    • Buy cheap 1.2°3phase Hybrid Stepper Motor-NEMA42 from wholesalers

    1.2°3phase Hybrid Stepper Motor-NEMA42

    Ask Lasest Price
    Brand Name : DAITTO
    Certification : ISO,CE
    Model Number : DA110H3P-3013
    • Product Details
    • Company Profile

    1.2°3phase Hybrid Stepper Motor-NEMA42


    Genaral Specification:

    Item
    Specifications
    Step Angle
    1.2°
    Temperature Rise
    80℃max
    Ambient Temperature
    -20℃~+50℃
    Insulation Resistance
    100 MΩ Min. ,500VDC
    Dielectric Strength
    500VAC for 1minute
    Shaft Radial Play
    0.02Max. (450g-load)
    Shaft Axial Play
    0.08Max. (450g-load)
    Max. radial force
    75N (20mm from the flange)
    Max. axial force
    15N

    Electrical Specification:

    Model No.
    Step Angle
    Motor Length
    Current
    /Phase
    Resistance
    /Phase
    Inductance
    /Phase
    Holding Torque
    Motor
    Length
    ( °)
    (L)mm
    A
    Ω
    mH
    N.m
    Kg
    DA110H3P-3008
    1.2
    102
    3
    3.15
    17
    8
    5
    DA110H3P-3013
    1.2
    132
    3
    4.2
    22.6
    13
    6.6
    DA110H3P-5016
    1.2
    183
    5
    2.14
    17.5
    16
    9
    DA110H3P-5020
    1.2
    220
    5
    2.4
    24.4
    20
    11.1
    DA110H3P-5025
    1.2
    250
    5
    2.9
    27
    25
    13

    *We can produce it according your requests
