    Submersible Pump(550B)

    Ask Lasest Price
    Brand Name : DAITTO
    Model Number : Submersible Pump(370B) Submersible Pump(750B) Submersible Pump(550B)
    Supply Ability : 100000
    • Product Details
    • Company Profile

    Submersible Pump(550B)

    APPLICATION AREA:
    For countryside lifting water from wells,water supply and drainage of farmland, garden,and daily life. Drainage of industry ponding,building construction and breeding.

    OPERATING LIMITS:
    Trans medium PH 6.5-8.5
    Fluid temperature limit: <40 oC
    Max ambient temperature: 40 oC
    Operating depth: 5m

    STRUCTURAL CHARACTERISTICS:
    Insulation Class:E

    Protection Class: IPX8


    TYPE

    Submersible Pump

    MODEL

    QDX3-20-0.55B

    QDX10-10-0.55B

    QDX15-7-0.55B

    power(HP)

    0.75

    0.75

    0.75

    power(Kw)

    0.55

    0.55

    0.55

    RATED head(m)

    20

    10

    7

    RATED flow

    3 M³/H

    10 M³/H

    15 M³/H

    Inlet/Outlet

    1

    1.5

    2

    Gross Weight(kg)

    15

    16

    16.5

    Packing Dimersion(mm)

    415*190*230

    415*190*230

    420*225*195
